Ceramic Fiber Paper (MI-HICERA)

Ceramic Fiber Paper (MI-HICERA)

By Asbestos & Non-Asbestos Heat Insulation Products

MI-HICERA is Ceramic Fiber Paper, which is manufactured from Ceramic Bulk Fiber comprising high-temperature resistant inorganic refractory oxides of “Alumina” & “Silica.” The Ceramic Paper is manufactured in a very systematic method involving various processes. The product contains a small percentage of organic material to give it an extra ordinary pliability. Ceramic Fiber Paper features low thermal conductivity, excellent thermal shock stability, and chemical corrosion resistance. It exhibits excellent non-wetting characteristics i.e., it is unaffected by incidental spill of oil & water and its thermal and physical properties restored after drying. The Ceramic Paper, due to its inherent characteristics, it the right choice for applications requiring direct contact with molten Aluminum & Zinc.

APPLICATIONS It is an excellent substitute to Asbestos products insulation. It can be used as Gasketing between Aluminum and Zinc trough sections, for Aluminum Casting and Fabrication, Refractor back-up lining & insulation for Induction Furnaces & other Industrial Equipments, Insulation Packing in the form of Gaskets for any High Temperature applications, for Hot Top Lining & Combustion Chamber Liners etc.
CLASSIFICATION TEMPERATURE 1260 C
MELTING POINT 1750 C
THERMAL CONDUCTIVITY 0.13 W/m K (at 600 C)
LINEAR SHRINKAGE 3.5% maximum at 1260 C for 24 hours
AVERAGE DENSITY 200 - 220 Kg/m3
TENSILE STRENGTH 750 kN/m2
STANDARD SIZES Width - 1220 mm & other on request; Thickness - 2 mm, 3 mm, 5 mm & other on request
